Portable Electromagnetic Cutting Machine
PRODUCT CODE : MW2500-048
FEATURES
- This magnetic cutting machine is mainly used for annular cutting
- Coolant tank is integrated with the machine body for more stable can reduce damage due to the external impact
- Compliant with CE standard (Optional)
DESCRIPTION
- Suitable for cutting holes on the objects which are hard to move, like steam boilers, heavy machines, and the building reinforcing beams
- The cutting capacity is from 16mm~52mm
- The up/down transmission of the tool bit is of the round shaft gear rack, so the drilling quality is good as the holes will not skew to one side
SPEC
- Power (AC) / Motor Rated Output / Motor Rated Ampere:
- (1) 110V , 230V / 1350W / 12A
- (2) 220V , 230V/ 1350W / 6.5A
- R.P.M.: 380 / 730
- Feeding Stroke: 82mm
- Hole Capacity: 5/8"~2" (16~52mm)
- Magnetic: 200 x 112 x 78mm
- Magnetic Force: 1500kgs
- Height: 480mm
- Machine Weight: 27kgs
- The product pictures are for your reference only: final spec & accessories based on formal quotation
-
FEATURES
- This magnetic cutting machine is mainly used for annular cutting
- Coolant tank is integrated with the machine body for more stable can reduce damage due to the external impact
- Compliant with CE standard (Optional)
-
DESCRIPTION
- Suitable for cutting holes on the objects which are hard to move, like steam boilers, heavy machines, and the building reinforcing beams
- The cutting capacity is from 16mm~52mm
- The up/down transmission of the tool bit is of the round shaft gear rack, so the drilling quality is good as the holes will not skew to one side
-
SPEC
- Power (AC) / Motor Rated Output / Motor Rated Ampere:
- (1) 110V , 230V / 1350W / 12A
- (2) 220V , 230V/ 1350W / 6.5A
- R.P.M.: 380 / 730
- Feeding Stroke: 82mm
- Hole Capacity: 5/8"~2" (16~52mm)
- Magnetic: 200 x 112 x 78mm
- Magnetic Force: 1500kgs
- Height: 480mm
- Machine Weight: 27kgs
- The product pictures are for your reference only: final spec & accessories based on formal quotation
- Power (AC) / Motor Rated Output / Motor Rated Ampere:
